XLamp CXA1304

High lumen output and efficacy from a compact, easy-to-use LED array

The new XLamp® CXA1304 LED Array is the most compact member of the CXA family, delivering up to 1034 lumens in a 6-mm optical-source size and enables lighting manufacturers to rapidly address small-form-factor lighting applications. The XLamp CXA1304 LED Array delivers high lumen output and high efficacy in a single, easy-to-use package that eliminates the need for reflow soldering. Optimized to simplify designs and lower system cost, the CXA1304 LED Array can enable system-level performance of 250 to 800 lumens.

Application

Non-Directional

Directional

Downlights
